Standard Features:

Resolution

• 203 dpi/8 dots per mm

Memory

• 512 MB Flash; 256MB SDRAM
• 64 MB user available non-volatile memory
• 8 MB user available SDRAM

Print width

• 4.09 in./104 mm for 203 dpi
• 4.27 in./108 mm for 300 dpi
• Cartridge: 4.09 in./104 mm for 203 and 300 dpi

Print length

• Maximum: 39.0 in./991 mm
• Minimum: 0.25 in./6.4 mm

Print speed

• 6 in./152 mm per second (203 dpi)
• 4 in./102 mm per second (300 dpi)

Media sensors

• Full width, moveable reflective/black mark sensor; multi-position transmissive/gap sensor

Media, and Cartridge Characteristics

• Maximum Label Length

  Maximum: 39.0 in./991 mm
  Minimum: 0.25 in./6.4 mm
• Media Width

  Direct Thermal: 0.585 in./15 mm to 4.25 in./108 mm
  Thermal Transfer Roll: 0.585 in./15 mm to 4.41 in./ 112 mm
  Thermal Transfer Cartridge: 0.585 in./15 mm to 4.65 in./118 mm
• Media Roll Size

  Maximum outer diameter: 5.00 in./127 mm
  Core inner diameter: 0.5 in. (12.7 mm) and 1.0 in.
  (25.4 mm) standard, 1.5 in. (38.1), 2.0 in., (50.8 mm)
  and 3.0 in. (76.2 mm) using optional adapters
• Thickness
  0.003 in. (0.08 mm) min.; 0.0075 in. (0.19 mm) max.

Media Types

• Roll-fed or fan-fold, die cut or continuous with or without black mark, tag stock, continuous receipt paper, and wristbands.

Operating characteristics

• Operating Temp. 40° to 105° F/4.4° to 41° C
• Storage Temp. -40° to 140° F/-40° to 60° C
• Operating Humidity: 10% to 90% non-condensing
• Storage Humidity: 5% to 95% non-condensing
• Electrical: Auto-detectable (PFC Compliant) 100-240VAC, 50-60Hz; ENERGY STAR certified; Energy Efficiency Level VI certified;
  optional 2750 mAh battery; Healthcare models include IEC60601-1 certified power supply

• Thermal Transfer Roll:
  10.5 in. L x 8.0 in. W x 7.44 in. H
  267 mm L x 202 mm W x 189 mm H
• Thermal Transfer Cartridge:
  10.0 in. L x 8.0 in. W x 7.0 in. H
  254 mm L x 202 mm W x 177 mm H

Electrical specifications

Auto-detectable (PFC Compliant) 100-240VAC,
