The TSC TH240T is a 203 dpi desktop thermal label printer developed for organisations that need reliable barcode, shipping, inventory and product-label printing without moving to a larger industrial printer.

It can print using either a thermal-transfer ribbon or direct-thermal label material. This makes the printer suitable for both temporary labels and labels requiring improved resistance to handling, moisture, abrasion or storage conditions.

• 4-inch desktop barcode and label printer
• Thermal-transfer and direct-thermal printing
• 3.5-inch colour touchscreen
• Wired network connectivity included
• Supports 300 metre and 110 metre ribbons
• Designed for thick, small, long and specialised label formats
• Suitable for centralised or distributed printer management

This product listing is for the Australian TSC TH240-A001-0004 configuration.

Optional wireless modules are sold separately. Confirm compatibility, availability and installation requirements before ordering a wireless upgrade.

The 203 dpi TH240T is well suited to general barcode, logistics, product and inventory labels. Applications requiring very small text, compact two-dimensional barcodes or finer graphics should be assessed for the separate 300 dpi TH340T model.

The printer uses transmissive gap sensing and an adjustable reflective black-mark sensor. It also includes ribbon-end and printhead-open sensors.

Media performance can depend on label construction, liner, perforations, adhesive, thickness and environmental conditions. Testing is recommended for unusual, transparent, very small or specialised label materials.

The TSC TH240T supports both long desktop ribbons and smaller half-inch-core ribbons.

Wax, wax-resin or resin ribbon selection should be matched to the label face material and the required resistance to abrasion, chemicals, heat, moisture and outdoor exposure.

The TH240T includes a 3.5-inch colour touchscreen with a 480 × 320-pixel display. The printer also includes dedicated power, feed, pause and reprint controls.

The display provides access to printer settings and status information, helping operators identify media, ribbon and print configuration issues without relying entirely on a connected computer.

TSC also incorporates self-diagnostic and maintenance features, including printhead monitoring, ribbon-low warning and toolless replacement of key service components.

The TH240T uses the TSPL-EZD printer language and is compatible with common EPL, ZPL, ZPL II and DPL printing environments.

TSC's automatic printer-language emulation is designed to recognise major command languages and assist with deployment into existing labelling environments without requiring every template to be redesigned.

• TSPL and TSPL-EZD
• EPL compatibility
• ZPL and ZPL II compatibility
• DPL compatibility
• UTF-8 TrueType font support
• Font and barcode rotation at 0, 90, 180 and 270 degrees

The printer can be used with BarTender and other compatible professional label-design and print-automation platforms. Software edition requirements depend on the number of printers, users, databases, integrations and automated workflows required.

The TH240T supports a broad range of commonly used one-dimensional and two-dimensional barcode formats.

Common 1D barcode formats include:

• Code 39 and Code 93
• Code 128 and Code 128 UCC
• EAN-8, EAN-13 and EAN-128
• UPC-A and UPC-E
• Interleaved 2 of 5
• ITF-14 and EAN-14
• Codabar
• MSI and Plessey
• POSTNET and PLANET
• GS1 DataBar

Common 2D barcode formats include:

• QR Code
• Data Matrix
• PDF417 and Micro PDF417
• Aztec
• MaxiCode
• CODABLOCK F

Barcode readability depends on label size, print resolution, quiet zones, print darkness, print speed, ribbon and label compatibility, barcode dimensions and scanner capability.

Because Ethernet is included with the stocked model, the TH240T can be incorporated into wired network environments and managed using supported TSC printer-management tools.

• Internal Embedded Webpage
• Virtual Control Panel
• TSC Console
• TSC Console Web
• SOTI Connect compatibility

These tools can assist with printer status monitoring, configuration, troubleshooting, maintenance planning and firmware management.

Supported network-security capabilities include HTTPS, SNMPv3, 802.1X and TCP/IP Port 9100 filtering. Deployment and security settings should be reviewed by the organisation's network administrator.

The standard TH240-A001-0004 supplied on this page does not include a cutter, peeler, Wi-Fi, Bluetooth or RFID hardware.

Compatible options may include:

• Peel-off module
• Guillotine cutter with full-cut and partial-cut operation
• Care-label cutter
• Wi-Fi and Bluetooth combination module
• Bluetooth module
• External label-roll mount
• 10 mm narrow-media adaptor
• Compatible external UHF RFID tear-off or cutter module

Internal RFID configurations are factory-built models. A standard non-RFID TH240 may instead be paired with a compatible external RFID tear-off or cutter module.

RFID options enable compatible labels to be printed and encoded in one workflow. RFID media, inlay compatibility, frequency, encoding position and read/write performance should be validated for the intended application before deployment.

Optional accessories are sold separately and may require installation. Contact Label Power to confirm the correct accessory part number for your printer and application.

The model offered on this page is the 203 dpi TH240T. The 300 dpi TH340T is a separate printer model.

Resolution cannot normally be changed by selecting a software setting. Choose the correct printer model for the required label design and barcode size.

The TSC TH240T is suitable for a broad range of Australian label and barcode printing applications, including:

• 100 × 150 mm shipping and freight labels
• Warehouse picking and receiving labels
• Inventory and stock-location labels
• Product and item identification
• Retail shelf and price labels
• Food and beverage product labels
• Batch, date and traceability labels
• Healthcare specimen and pharmacy labels
• Patient and sample tracking
• Apparel hang tags and care labels
• Asset-identification labels
• QR Code and GS1 barcode labels
• Transport and logistics documentation

For very high print volumes, continuous production, harsh environments or large external media rolls, an industrial label printer may be more appropriate.

The TSC TH Series has been developed with reduced end-of-life waste and recyclable materials in mind.

• 100% recyclable packaging
• FSC-compliant packaging cartons
• 100% recyclable plastic printer casing
• Printer casing manufactured using 30% recycled plastic
• More than 90% of printer components are recyclable
• RoHS, REACH, WEEE and China RoHS environmental compliance

Actual recycling options depend on the recycling facilities and electronic-waste programs available in your area.

The standard manufacturer package includes:

• TSC TH240T printer
• Quick-start guide
• USB cable
• Australian power cord
• External universal power supply
• Two 1-inch ribbon spindles for 300 metre ribbons
• One 1-inch ribbon paper core
• Media adaptor for media up to 120 mm wide

Labels, thermal-transfer ribbons, optional modules and advanced BarTender editions are sold separately unless specifically included in a bundle.

Warranty coverage is subject to the manufacturer's terms, installation, usage, maintenance, approved consumables and assessment procedures. Statutory rights may also apply.

Does the stocked TSC TH240T include Wi-Fi or Bluetooth?

No. Model TH240-A001-0004 includes USB, RS-232 serial, Ethernet and USB Host connectivity. Wi-Fi and Bluetooth require a compatible optional module.

Can the TH240T print both direct-thermal and thermal-transfer labels?

Yes. It can print direct-thermal labels without a ribbon or use a thermal-transfer ribbon for improved durability and a wider choice of label materials.

Can the TH240T print standard 100 × 150 mm shipping labels?

Yes. The printer supports media up to 120 mm wide and has a maximum print width of 108 mm, making it suitable for common 100 × 150 mm freight and shipping labels.

Does the TH240T use 300 metre ribbons?

Yes. It supports 300 metre ribbons on a 1-inch core and 110 metre ribbons on a 0.5-inch core. Compatible ribbons must be ink-coated outside and between 40 mm and 110 mm wide.

Is a 300 dpi version available?

Yes. The 300 dpi version is the separate TSC TH340T model. The resolution is determined by the printer model and is not changed through a driver setting.

Can a cutter or peel-off module be added?

Yes. Compatible guillotine-cutter and peel-off modules are available separately. Confirm the correct part number and installation requirements before ordering.

Can a standard TH240T be upgraded for RFID printing?

Compatible external UHF RFID tear-off and cutter modules are available for selected TH240 configurations. Built-in RFID is a factory configuration. RFID media and module compatibility should be confirmed before purchase.

What label software can be used with the TH240T?

TSC provides access to BarTender UltraLite for basic label design. More advanced BarTender editions are available for databases, integrations, automation, centralised management and larger printing environments.

Does the printer support ZPL label formats?

The TH240T uses TSC's TSPL-EZD printer language and provides compatibility with ZPL, ZPL II, EPL and DPL printing environments. Template testing is recommended when replacing a different printer brand.
